Refrigeration System for a 75 Cubic Meters Freezer Room

Description

Components:

Air cooler

• Minimum cooling capacity of 7500 W at -25 degrees Celsius,
• Dimensions 1500 x 600 x 550 mm,
• Equipped with two electric fan motors with a 400 mm blade diameter, powered by 230V / 50 Hz,1440 RPM, model EBM or a similar one.
• Includes a thermostatic expansion valve with Danfoss equalization, with orifice sizes of 5 or 6 tons, and 150mm ceiling-mounting studs.
• Equipped with four defrost heating elements, each with a minimum power of 1500 W.

Control Panel

• Metal or ABS (upon request),
• Eliwell with a controller from the IDplus 9xx series.
• Features 25A relays/contactors, and protection elements for overvoltage, overcurrent, phase loss, and phase sequence (for three-phase units).
• Contains two NTC sensors for monitoring the room and coil temperature (defrost and ventilation control).

Condensing Unit

• Equipped with a hermetic compressor with a minimum cooling capacity of 7500 W at -25 degrees Celsius evaporation temperature.
• Includes an oversized air-cooled condenser, a minimum 10-liter receiver, a differential pressure switch, a 465 g filter drier with a 5/8" connection, and an electrical connection box.
• Available in three-phase options. Types of hermetic compressors include Copeland Scroll, Tecumseh, Sanyo, Toshiba, or semi-hermetic Bitzer and Frascold.
• Energy efficiency class A, with a maximum power consumption of 5500 W.
• Upon request and at an additional cost, it can be equipped with a liquid separator, oil separator, heat recovery unit, or delivered in a quiet, enclosed version.

Refrigeration Line:

• 4 m of copper pipes, 1/2" and 7/8" (12 mm and 22 mm),
• Insulation for the suction line, drain tube, insulation jacketing, electrical cables, flare nuts, heating element, and insulation for the drain tube.

Achieved temperature inside the room: -18...-20°C.

Condition: All components are new.

The price does not include delivery, installation, commissioning, or tests. (7,250 RON + VAT)

System warranty: 24 months.

Due to of the wide range of operating pressures that Copeland, Bristol, and Tecumseh compressors can handle, this system is suitable for cold rooms of up to 135 cubic meters.

It is also available with a quiet, enclosed refrigeration unit for just 29,500 RON + VAT
