Freezing System for a 70 Cubic Meter Cold Room

Description

Components:

Freezer Air Cooler

• Minimum cooling capacity: 7,350 W at an evaporation temperature of -25°C.
• Dimensions: 1500 x 600 x 550 mm.
• Equipped with two electric fan motors, 400 mm blade diameter, powered at 230V / 50 Hz, 1440 RPM, model EBM.
• Thermostatic expansion valve with external Danfoss equalization, 5 or 6-ton orifice size, and 150 mm ceiling mounting studs.
• The air cooler includes four defrost heating elements, each with a minimum power output of 1,500 W.

Automation Control Panel

• Available in metal or ABS (upon request), equipped with an Eliwell IDplus 9xx series controller.
• Includes 25 A relays/contactors, overvoltage protection, overcurrent protection, phase loss protection, and phase sequence control (for three-phase systems).
• Comes with two NTC sensors: one for room temperature and one for coil monitoring (defrost and ventilation control).

Condensing Unit

• Equipped with a hermetic compressor, with a minimum cooling capacity of 6,500 W at an evaporation temperature of -25°C.
• Includes an air-cooled condenser coil, a minimum 10-liter liquid receiver, differential pressure switch, 465-gram filter drier with 5/8" connections, and an electrical junction box.
• Available in a three-phase version.
• Hermetic compressor brands: Copeland Scroll, Tecumseh, Sanyo, Toshiba, or semi-hermetic compressors from Bitzer, Frascold.
• Energy efficiency class A. Maximum electrical power consumption: 4,500 W.
• Upon request and for an additional cost, the unit can be equipped with a liquid separator, oil separator, heat recovery unit, or delivered in a quiet, enclosed version.

Refrigeration Line

• 4 meters of copper piping: 3/8" (10 mm) and 3/4" (19 mm).
• Includes suction line insulation, drain tubing, jacketing (tape-wrapped), electrical cables, flare nuts, heating element, and insulation for the drain tube.

Achievable room temperature: -18°C to -20°C.

Installation labor cost: 6,950 RON.

Condition: All products are new.

Price does not include delivery, installation, start-up, or tests.

System warranty: 24 months.

Due to the broad operating pressure range of the Copeland, Bristol, and Tecumseh compressors, this system is also suitable for cold rooms with capacities of up to 125 cubic meters.

Also available in a version with a quiet, encased condensing unit for only 29,850 RON + VAT.
