Fan Speed Controller | Danfoss XGE-4CB1
RON 650.00
(VAT included.)
Delivery costs are not included.
How can we help you?
Description
The Danfoss XGE-4CB1 is an automatic fan speed controller for condenser fans, that adjusts fan speed according to the condensing pressure.
Power supply: 200–240 V AC, 50/60 Hz, single-phase
Pressure control range: 10–25 bar
Factory setting: 19 bar
Maximum operating pressure: 47 bar
Operating mode: Cut-off (the fan switches off when the pressure falls below the control range)
Pressure connection: 1/4" male
Compatible refrigerants: R407C, R404A, R134a, R22
Protection rating: IP65
Maximum output current: 3 A
Ambient temperature range: -20°C to +55°C
Condition: Used
